Production facilities
Dissolution/alloy furnace
(Reverberatory furnace)
(Reverberatory furnace)
| 60Ton | 45Ton | 30Ton | 20Ton |
|---|---|---|---|
| 1 | 1 | 1 | - |
Supply facilities of molten metal
| Holding furnace of molten metal | Pre-heater of molten metal ladle | Molten metal ladle |
|---|---|---|
| No.1 45t furnace | No. 11 | 1.5Ton X No.26 |
Revolting furnace
| 7 Ton | 8 Ton |
|---|---|
| 1 | - |
re-revolving furnace & re-cooler
| 800kg/one time | 600kg/one time |
|---|---|
| No. 2 | - |
Continuous caster & Leg Continuous Casting Machine
| 800kg/one time | 600kg/one time |
|---|---|
| 4 | 1 |
Automatic Stacking Machine
| 1Ton/Loading 500kg |
|---|
| No. 4 |
Flux processor
| Flux Injection M | G.B.F |
|---|---|
| No. 4 | No. 3 |
ollution prevention equipment
(dust collector)
(dust collector)
| 1600㎥/min | 900㎥/min | 700㎥/min | 500㎥/min |
|---|---|---|---|
| 1 | 3 | 1 | 1 |
Molten metal G.B.F
| Molten metal G.B.F |
|---|
| 1기 |
